| Operation
Level (Taxonomy) |
Operation Type | Pentaho PDI | Talend Data Integration | SSIS | Oracle Warehouse Builder |
| Attribute | Attribute Value Alteration | Add constant Formula Number ranges Add sequence Calculator Add a checksum |
tMap tConvertType tReplaceList |
Character Map Derived Column Copy Column Data Conversion |
Constant Operator Expression Operator Data Generator Transformation Mapping Sequence |
| Dataset | Duplicate Removal | Unique Rows Unique Rows (HashSet) |
tUniqRow | Fuzzy Grouping | Deduplicator |
| Sort | Sort Rows | tSortRow | Sort | Sorter | |
| Sampling | Reservoir Sampling Sample Rows |
tSampleRow | Percentage Sampling Row Sampling |
||
| Aggregation | Group by Memory Group by |
tAggregateRow tAggregateSortedRow |
Aggregate | Aggregator | |
| Dataset Copy | tReplicate | Multicast | |||
| Entry | Duplicate Row | Clone Row | tRowGenerator | ||
| Filter | Filter Rows Data Validator |
tFilterRow tMap tSchemaComplianceCheck |
Conditional Split | Filter | |
| Join | Merge Join Stream Lookup Database lookup Merge Rows Multiway Merge Join Fuzzy Match |
tJoin tFuzzyMatch |
Merge Join Fuzzy Lookup |
Joiner Key Lookup Operator |
|
| Router | Switch/Case | tMap | Conditional Split | Splitter | |
| Set Operation - Intersect | Merge Rows (diff) | tMap | Merge Join | Set Operation | |
| Set Operation - Difference | Merge Rows (diff) | tMap | Set Operation | ||
| Set Operation - Union | Sorted Merge Append streams |
tUnite | Merge Union All |
Set Operation | |
| Schema | Attribute Addition | Set field value Set field value to a constant String operations Strings cut Replace in string Formula Split Fields Concat Fields Add value fields changing sequence Sample rows |
tMap tExtractRegexFields tAddCRCRow |
Derived Column Character Map Row Count Audit Transformation |
Constant Operator Expression Operator Data Generator Mapping Input/Output parameter |
| Datatype Conversion | Select Values | tConvertType | Data Conversion | Anydata Cast Operator | |
| Attribute Renaming | Select Values | tMap | Derived Column | ||
| Projection | Select Values | tFilterColumns | |||
| Relation | Pivoting | Row Denormalizer | tDenormalize tDenormalizeSortedRow |
Pivot | Unpivot |
| Unpivoting | Row Normalizer Split field to rows |
tNormalize tSplitRow |
Unpivot | Pivot | |
| Value | Single Value Alteration | If field value is null Null if Modified Java Script Value SQL Execute |
tMap tReplace |
Derived Column | Constant Operator Expression Operator Match-Merge Operator Mapping Input/Output parameter |
| Source Operation | Extraction | CSV file input Microsoft Excel Input Table input Text file input XML Input |
tFileInputDelimited tDBInput tFileInputExcel |
ADO .NET /
DataReader Source Excel Source Flat File Source OLE DB Source XML Source |
Table Operator Flat File Operator Dimension Operator Cube Operator |
| Target Operation | Loading | Text file output Microsoft Excel Output Table output Text file output XML Output |
tFileOutputDelimited tDBOutput tFileOutputExcel |
Dimension Processing Excel Destination Flat File Destination OLE DB Destination SQL Server Destination |
Table
Operator Flat File Operator Dimension Operator Cube Operator |
